Cross-section of the
epidermis
and the mesophyll (constituted by the
spongy
and
palisade parenhyma)
stained with Alcian blue-safranin and observed with objective of 4x. We
can notice different sections of the
vascular bundles
(the main and secondary vascular bundles), some in longitudinal section.
In the lower epidermis appear some
stomatal crypts.
Details of the mesophyll and the main bundle are shown at higher
magnification in other microphotographies (zones framed in red and blue,
respectively)
|
